Quarter LED - PXF Lighting

Product variants

Suche

Filtry

How does the product indexing system work?

002

830

Family

AA ALTO LED

AB ALTO WALL

Type

001 e.g.: 545 mm

002 e.g.: 1085 mm

Farbe

11 WHITE RAL 9016

12 WHITE RAL 9010

22 GREY RAL 9006

33 BLACK RAL 9005

44 ANTHRACITE RALBG 452

45 ANTHRACITE RAL 7016

99 OTHER - PERSONALIZATION

Optisches System

00 EMPTY

11 OPAL /MILK DIFFUSER/

22 MPRM /MICROPRISMATIC DIFFUSER/

23 DMPRM /DIAMONT MICROPRISMATIC DIFFUSER/

24 MPOP /MICROPRISMATIC DIFFUSER WITH FLEX LAYER/

33 PAR /PARABOLIC LOUVER/

34 PAR SH /PARABOLIC LOUVER UNDER TEMPERED GLASS/

44 mPARM /PARABOLIC MINI LOUVER METALLIZED/

45 PARW /PARABOLIC LOUVER WHITE/

46 mPARB /PARABOLIC MINI LOUVER BLACK/

66 RF /REFLECTOR/

67 RM /MATTE REFLECTOR/

68 RW /REFLECTOR WHITE/

77 LNS /LENS/

88 SH MAT /MATTE TEMPERED GLASS/

89 SH /TEMPERED GLASS/

CRI /Farbtemperatur

827

830 CRI ≥ 80; CCT 3000K

835 CRI ≥ 80; CCT 3500K

840 CRI ≥ 80; CCT 4000K

850 CRI ≥ 80; CCT 5000K

857 CRI ≥ 80; CCT 5700K

865 CRI ≥ 80; CCT 6500K

8TW CRI ≥ 80; Tunable white

927 CRI ≥ 90; CCT 2700K

930 CRI ≥ 90; CCT 3000K

935 CRI ≥ 90; CCT 3500K

940 CRI ≥ 90; CCT 4000K

950 CRI ≥ 90; CCT 5000K

957 CRI ≥ 90; CCT 5700K

965 CRI ≥ 90; CCT 6500K

9TW CRI ≥ 90; Tunable white

RGB RGB

Netzteil

A ON/OFF /WITHOUT REGULATION/

D DALI /DIGITAL ADDRESSABLE LIGHTING INTERFACE/

H HO /DRIVER WITH PREDEFINED SETTING/

E HE /DRIVER WITH PREDEFINED SETTING/

F HO DALI /DRIVER WITH PREDEFINED SETTING/

G HE DALI /DRIVER WITH PREDEFINED SETTING/

K DSI

I CF /CORRIDOR FUNCTION - STEP DIMMING/

C CAS /CASAMBI - SMART CONTROL VIA APPLICATIONS/

X DMX

S sDIMM

V 1-10V /ADJUSTABLE/

Emergency module

0 WITHOUT EMERGENCY MODULE

1 EM1H ST /SELFTEST/

2 EM3H ST /SELFTEST/

3 EM1H BASIC

4 EM3H BASIC

5 EM1H PRO /DALI/

6 EM3H PRO /DALI/

Through wiring

0 WITHOUT THROUGH WIRING

1 TH3 /3-PHASE THROUGH WIRING/

2 TH5 /5-PHASE THROUGH WIRING/

3 TH7 /7-PHASE THROUGH WIRING/

4 WI /WIELAND/

5 WI TH /THROUGH WIRING/

Bewegungssensor

0 WITHOUT MOTION SENSOR

1 MW PRO /PASSIVE INFRARED - STEP DIMM/

2 PIR /INFRARED/

Parametry

Index	Luminaire power	Leuchtenlichtstrom	Lichtausbeute der Leuchte	Raster/ Blendschutz [Optisches System]	Farbtemperatur / CRI	Farbe	Type of driver	Emergency module	Familientyp
DB001.1111.830.A000 Copy the code Open in new window	13 W	1150 lm	88 lm/W	OPAL	830	weiß	ON/OFF	Nein	13W
DB001.1111.840.A000 Copy the code Open in new window	13 W	1180 lm	91 lm/W	OPAL	840	weiß	ON/OFF	Nein	13W
DB001.2211.830.A000 Copy the code Open in new window	13 W	1150 lm	88 lm/W	OPAL	830	grau	ON/OFF	Nein	13W
DB001.2211.840.A000 Copy the code Open in new window	13 W	1180 lm	91 lm/W	OPAL	840	grau	ON/OFF	Nein	13W
DB001.3311.830.A000 Copy the code Open in new window	13 W	1150 lm	88 lm/W	OPAL	830	schwarz	ON/OFF	Nein	13W
DB001.3311.840.A000 Copy the code Open in new window	13 W	1180 lm	91 lm/W	OPAL	840	schwarz	ON/OFF	Nein	13W
DB001.3311.840.D000 Copy the code Open in new window	13 W	1180 lm	91 lm/W	OPAL	840	schwarz	DALI	Nein	13W

Index	Moc oprawy	Strumień świetlny oprawy	Długość [L]	Szerokość [W]	Wysokość / głębokość [H]
DB001.1111.830.A000 Copy the code Open in new window	13 W	1150 lm	400 mm	400 mm	62 mm
DB001.1111.840.A000 Copy the code Open in new window	13 W	1180 lm	400 mm	400 mm	62 mm
DB001.2211.830.A000 Copy the code Open in new window	13 W	1150 lm	400 mm	400 mm	62 mm
DB001.2211.840.A000 Copy the code Open in new window	13 W	1180 lm	400 mm	400 mm	62 mm
DB001.3311.830.A000 Copy the code Open in new window	13 W	1150 lm	400 mm	400 mm	62 mm
DB001.3311.840.A000 Copy the code Open in new window	13 W	1180 lm	400 mm	400 mm	62 mm
DB001.3311.840.D000 Copy the code Open in new window	13 W	1180 lm	400 mm	400 mm	62 mm

Displaying items: 7 of 7

of 1

per page

Montagearten	Seilpendelmontage
Gehäuse-Material	Aluminium

Leuchtmittel	LED
Leuchtenanschlussleistung	13 W
Lieferbares Zubehör	Netzteil
Nennspannung	220 ... 240 V
Through wiring	Nein
mit Leuchtmittel bestückt	Ja
Power factor	0.96
Type of driver	DALI, ON/OFF
Emergency module	option
Bewegungssensor	option

Net weight	2.8 kg
Farbe	grau, schwarz, weiß
RAL – jede Farbe aus der Palette	Ja
Power and luminous flux tolerance	+/-10%

Leuchtenlichtstrom	1150 - 1180 lm
Lichtausbeute der Leuchte	88 - 91 lm/W
Lichtausbeute der Leuchte	60
Lichtfarbe	weiss
Farbwiedergabeindex	80
Lichtverteilung	Lichtaustritt DI
MacAdam	SDCM 3
L80B10 @25°C	100000 h
L90B10 @25°C	64000 h
Lamp Lumen Maintenance Factor (after 60 000h)	86 %
Farbtemperatur	3000K, 4000K
Farbtemperatur / CRI	830, 840

Schutzart IP	IP20
Schlagfestigkeit	IK04
Schutzklasse	I
Power Flicker	=< 3%
Lampenschutz	Ja
CE	Ja
HACCP+	Ja

Raster/ Blendschutz	OPAL
Abdeckungsfarbe	weiß
Abdeckungsmaterial	Kunststoff opal / matt
