Virus XL - PXF

Product variants

Suche

How does the product indexing system work?

002

830

Family

AA ALTO LED

AB ALTO WALL

Type

001 e.g.: 545 mm

002 e.g.: 1085 mm

Farbe

11 WHITE RAL 9016

12 WHITE RAL 9010

22 GREY RAL 9006

33 BLACK RAL 9005

44 ANTHRACITE RALBG 452

45 ANTHRACITE RAL 7016

99 OTHER - PERSONALIZATION

Optical system

00 EMPTY

11 OPAL /MILK DIFFUSER/

22 MPRM /MICROPRISMATIC DIFFUSER/

23 DMPRM /DIAMONT MICROPRISMATIC DIFFUSER/

24 MPOP /MICROPRISMATIC DIFFUSER WITH FLEX LAYER/

33 PAR /PARABOLIC LOUVER/

34 PAR SH /PARABOLIC LOUVER UNDER TEMPERED GLASS/

44 mPARM /PARABOLIC MINI LOUVER METALLIZED/

45 PARW /PARABOLIC LOUVER WHITE/

46 mPARB /PARABOLIC MINI LOUVER BLACK/

66 RF /REFLECTOR/

67 RM /REFLECTOR METALLIZED/

68 RW /REFLECTOR WHITE/

77 LNS /LENS/

88 SH MAT /MATTE TEMPERED GLASS/

89 SH /TEMPERED GLASS/

CRI /Farbtemperatur

827

830 CRI ≥ 80; CCT 3000K

835 CRI ≥ 80; CCT 3500K

840 CRI ≥ 80; CCT 4000K

850 CRI ≥ 80; CCT 5000K

857 CRI ≥ 80; CCT 5700K

865 CRI ≥ 80; CCT 6500K

8TW CRI ≥ 80; Tunable white

927 CRI ≥ 90; CCT 2700K

930 CRI ≥ 90; CCT 3000K

935 CRI ≥ 90; CCT 3500K

940 CRI ≥ 90; CCT 4000K

950 CRI ≥ 90; CCT 5000K

957 CRI ≥ 90; CCT 5700K

965 CRI ≥ 90; CCT 6500K

9TW CRI ≥ 90; Tunable white

RGB RGB

Netzteil

A ON/OFF /WITHOUT REGULATION/

D HO /DRIVER WITH PREDEFINED SETTING/

H DSI

E HE /DRIVER WITH PREDEFINED SETTING/

F HO DALI /DRIVER WITH PREDEFINED SETTING/

G HE DALI /DRIVER WITH PREDEFINED SETTING/

K CAS /CASAMBI - SMART CONTROL VIA APPLICATIONS/

I CF /CORRIDOR FUNCTION - STEP DIMMING/

C DALI /DIGITAL ADDRESSABLE LIGHTING INTERFACE/

X 1-10V /ADJUSTABLE/

S DMX

V sDIMM

Emergency module

0 WITHOUT EMERGENCY MODULE

1 EM1H ST /SELFTEST/

2 EM3H ST /SELFTEST/

3 EM1H BASIC

4 EM3H BASIC

5 EM1H PRO /DALI/

6 EM3H PRO /DALI/

Through wiring

0 WITHOUT THROUGH WIRING

1 TH3 /3-PHASE THROUGH WIRING/

2 TH5 /5-PHASE THROUGH WIRING/

3 TH7 /7-PHASE THROUGH WIRING/

4 WI /WIELAND/

5 WI TH /THROUGH WIRING/

Bewegungssensor

0 WITHOUT MOTION SENSOR

1 MW PRO /PASSIVE INFRARED - STEP DIMM/

2 PIR /INFRARED/

Filtry

Parametry

Anuluj

Show products

Index	Lampenanschlussleistung	Lampenanzahl	Farbe
EO001.1100.000.A000 Copy the code Open in new window	15 W	2	weiß
EO002.1100.000.A000 Copy the code Open in new window	15 W	2	weiß
EO003.1100.000.A000 Copy the code Open in new window	15 W	2	weiß
EO004.1100.000.A000 Copy the code Open in new window	30 W	2	weiß
EO005.1100.000.A000 Copy the code Open in new window	15 W	3	weiß
EO006.1100.000.A000 Copy the code Open in new window	15 W	3	weiß
EO007.1100.000.A000 Copy the code Open in new window	15 W	3	weiß
EO008.1100.000.A000 Copy the code Open in new window	30 W	3	weiß

Index	Wysokość / głębokość [H]
EO001.1100.000.A000 Copy the code Open in new window	175 mm
EO002.1100.000.A000 Copy the code Open in new window	175 mm
EO003.1100.000.A000 Copy the code Open in new window	175 mm
EO004.1100.000.A000 Copy the code Open in new window	175 mm
EO005.1100.000.A000 Copy the code Open in new window	175 mm
EO006.1100.000.A000 Copy the code Open in new window	175 mm
EO007.1100.000.A000 Copy the code Open in new window	175 mm
EO008.1100.000.A000 Copy the code Open in new window	175 mm

Displaying items: 8 of 8

of 1

per page

Montagearten	Universal
Gehäuse-Material	Aluminium

Abdeckungsmaterial	Nein
Spiegelraster	high gloss

Leuchtmittel	G13
Fassung	G13
Lieferbares Zubehör	Netzteil
mit Zündungssystem bestückt	Ja
Nennspannung	220 ... 240 V
Through wiring	Nein
mit Leuchtmittel bestückt	Ja
Type of driver	ON/OFF
Emergency module	opcjonalnie
Bewegungssensor	opcjonalnie

Net weight	7 - 10 kg
Farbe	weiß
Inne	UV-C lamps for purification T8/G13/ HNS OFR
Info	Stand, Stand Mobile

Schutzart IP	IP20
Lampenschutz	Ja
PZH	Ja
CE	Ja
HACCP+	Ja
EAC	Ja
