Linear
Alto LED DI-IN 1085 37W 2290/1110lm 940 OPAL White TH5
New LED lighting system designed for inline installation. ALTO LED is an elegant and efficient luminaire for lighting offices, conference rooms, receptions and other working spaces.
Linear
Alto LED DI-IN 1085 37W 2290/1110lm 940 OPAL White TH5
New LED lighting system designed for inline installation. ALTO LED is an elegant and efficient luminaire for lighting offices, conference rooms, receptions and other working spaces.
LED
DI/IN
IP20
I
yes
yes
yes
Basic information:
Index:
AA005.1111.940.A020
EAN:
5907671354553
Accessories:
Alto End cap, Electric suspension kit, Alto joining set, Suspension kit 1x
Installation:
suspended
Power:
220 ... 240  V
Categorization:
Type of luminaire:
Linear
Application:
Office, Conference room, Corridor and staircase, Reception, Commercial premises, Lecture hall, Classroom, Computer lab
Mounting type:
Pendant
Technical data Download Accessories
Technical data
Alto LED DI-IN 1085 37W 2290/1110lm 940 OPAL White TH5
PRODUCT CODE
AA005.1111.940.A020
Copy the code
PRODUCT EAN
5907671354553
Copy the EAN code
Mechanical data
Housing material Aluminum
Designed for light-line yes
Optical data
Louver/ diffuser OPAL
Diffuser colour White
Diffuser material Opal/mat plastic
UGR 20
Electrical data
Light source LED
Luminaire power 37 W
Type of equipment AC
Voltage rating 220 ... 240 V
Through wiring TH5
Type of driver ON/OFF
Emergency module No
Motion sensor No
Information data
Net weight 2.4 kg
Colour White
Power and luminous flux tolerance +/-10%
Light data
Luminaire luminous flux DI 2290 lm
Luminaire luminous flux IN 1110 lm
Luminaire's luminous efficacy 92 lm/W
Color rendering index 90
Light distribution DI/IN
Colour temperature 4000K
CRI & colour temperature 940
Certificates
Degree of protection (IP) IP20
Impact resistance IK04
Class of protection I
Light source protection yes
CE yes
HACCP+ yes
EAC yes
Dimensions
L W
1085 mm 28 mm
L - Length
W - Width
Download
Catalogue card
Download
Family datasheet
Download
Family datasheet extended
Download
Installation manual
500.85 KB
Download
EC Declaration of conformity
Download
Pobierz wszystkie pliki
Structural elements
Accessories
Alto End cap
Electric elements
Accessories
Electric suspension kit
Connecting elements
Accessories
Alto joining set
Installation elements
Accessories
Suspension kit 1x
