Downlight

Bari ECO DL LOW LED

Go to the variant list (517)

tak

Basic information:

Power:

220 ... 240 V

Categorization:

Type of luminaire:

Downlight

Application:

Cloak room, Corridor and staircase, Reception, Commercial premises

Mounting type:

Plasterboard recessed

Technical data:

Luminaire power:

10 - 28 W

Luminaire luminous flux:

920 - 2830 lm

See other technical data

Technical data

Mechanical data

Type of installation	Recessed
Housing material	Aluminum

Optical data

Louver/ shutter	RF, RM, RW
Diffuser colour	Biały
Diffuser material	Opal/mat plastic
Reflector	o wysokim połysku, satin
UGR	19, 20, 21, 24, 25

Electrical data

Light source	LED
Luminaire power	10 - 28 W
Number of light sources	1
Voltage rating	220 ... 240 V
Through wiring	WI
Light source included	tak
Type of LED	5630
Type of driver	DALI, ON/OFF
Emergency module	opcjonalnie

Information data

Colour	White
Operating temperature range	-15 ... 40
Info	LOW, LOW MAT

Light data

Luminaire luminous flux	920 - 2830 lm
Luminaire's luminous efficacy	95 - 117 lm/W
Light colour	Biała
Color rendering index	84
Light distribution	Średniostrumieniowy
Light distribution	DI
Class of luminaire	I
Light output degradation	B10
Lumen maintenance	L80
Lifetime	54000
MacAdam	SDCM 3
LLMF - poziom strumienia początkowego po czasie 60 000h	86 %
Colour temperature	3000K, 4000K
CRI & colour temperature	830, 840, 930, 940

Certificates

Degree of protection (IP)	IP44
Degree of protection (IP) /top/	IP20
Stopień ochrony od dołu (IP)	IP44
Class of protection	II
PZH	tak
CE	tak
HACCP+	tak
EAC	tak

Product variants

Search

	Luminaire power	Luminaire luminous flux	Luminaire's luminous efficacy	Louver/ shutter [Układ optyczny]	CRI & colour temperature	Colour	Type of driver	Emergency module	Type of family
DK001.1166.930.D040 Copy the code	10 W	980 lm	98 lm/W	RF	930	White	DALI		10W 195mm
DK001.1166.930.D100 Copy the code	10 W	980 lm	98 lm/W	RF	930	White	DALI	EM1H ST	10W 195mm
DK001.1166.930.D140 Copy the code	10 W	980 lm	98 lm/W	RF	930	White	DALI	EM1H ST	10W 195mm
DK001.1166.930.D200 Copy the code	10 W	980 lm	98 lm/W	RF	930	White	DALI	EM3H ST	10W 195mm
DK001.1166.930.D240 Copy the code	10 W	980 lm	98 lm/W	RF	930	White	DALI	EM3H ST	10W 195mm
DK001.1166.940.A000 Copy the code	10 W	1000 lm	100 lm/W	RF	940	White	ON/OFF		10W 195mm
DK001.1166.940.A040 Copy the code	10 W	1000 lm	100 lm/W	RF	940	White	ON/OFF		10W 195mm
DK001.1166.940.A240 Copy the code	10 W	1000 lm	100 lm/W	RF	940	White	ON/OFF	EM3H ST	10W 195mm
DK003.1166.930.A240 Copy the code	15 W	1380 lm	92 lm/W	RF	930	White	ON/OFF	EM3H ST	15W 235mm
DK002.1167.930.D200 Copy the code	15 W	1280 lm	85 lm/W	RM	930	White	DALI	EM3H ST	15W 195mm
DK001.1168.840.D000 Copy the code	10 W	930 lm	93 lm/W	RW	840	White	DALI		10W 195mm
DK002.1167.930.D240 Copy the code	15 W	1280 lm	85 lm/W	RM	930	White	DALI	EM3H ST	15W 195mm
DK002.1166.830.A000 Copy the code	15 W	1560 lm	104 lm/W	RF	830	White	ON/OFF		15W 195mm
DK003.1166.930.D100 Copy the code	15 W	1380 lm	92 lm/W	RF	930	White	DALI	EM1H ST	15W 235mm
DK002.1167.830.A000 Copy the code	15 W	1500 lm	100 lm/W	RM	830	White	ON/OFF		15W 195mm

Displaying items: 15 of 517

of 35

per page
