Downlight

Bari ECO DLN IP65 LED 10W 1160lm 840 RF White STD

BARI ECO DLN IP65 LED extends the family of BARI ECO LED luminaires designed for ceiling mounting. Thanks to its impressive lighting performance and universal form, it can be used in most rooms where increased IP protection degree is required.

Image for the product family

Downlight

Bari ECO DLN IP65 LED 10W 1160lm 840 RF White STD

BARI ECO DLN IP65 LED extends the family of BARI ECO LED luminaires designed for ceiling mounting. Thanks to its impressive lighting performance and universal form, it can be used in most rooms where increased IP protection degree is required.

LED

IP65

yes

yes

yes

yes

Basic information:

Index:

DN001.1166.840.A000

EAN:

5907769492815

Accessories:

Bari DLN LED Suspension set 3x

Installation:

surface mounted

Power:

220 ... 240 V

Categorization:

Type of luminaire:

Downlight

Application:

Arcade, Swimming pool, Bathroom, Cloak room, Corridor and staircase, Technical room, Laboratory, Gym, Commercial premises, Reception, Infirmary, Social room, Doctor's office, Operating theatre, Treatment rooms, Industrial

Mounting type:

Ceiling mounted

Technical data

Bari ECO DLN IP65 LED 10W 1160lm 840 RF White STD

PRODUCT CODE

DN001.1166.840.A000

Copy the code

PRODUCT EAN

5907769492815

Copy the EAN code

Mechanical data

Type of installation	Surface mounted
Housing material	Aluminum

Optical data

Louver/ diffuser	RF
Reflector	high gloss
UGR	24

Electrical data

Light source	LED
Luminaire power	10 W
Number of light sources	1
Type of equipment	AC
Voltage rating	220 ... 240 V
Through wiring	No
Light source included	yes
Type of driver	ON/OFF
Emergency module	No
Motion sensor	No

Information data

Net weight	1.8 kg
Colour	White
Operating temperature range	-20 ... 40
Power and luminous flux tolerance	+/-10%

Light data

Luminaire luminous flux	1160 lm
Luminaire's luminous efficacy	116 lm/W
Light colour	White
Color rendering index	80
Light distribution	Średniostrumieniowy
Light distribution	DI
Class of luminaire	I
Light output degradation	B10
Lumen maintenance	L80
Lifetime	54000 h
MacAdam	SDCM 3
L80/B10 przy 25°C żywotność znamionowa [h]	54000 h
Lamp Lumen Maintenance Factor (after 60 000h)	86 %
Colour temperature	4000K
CRI & colour temperature	840

Certificates

Degree of protection (IP)	IP65
Impact resistance	IK02
Class of protection	I
PZH	yes
CE	yes
HACCP+	yes
EAC	yes

Dimensions

H	F
188 mm	245 mm

H - Height / Depth

F - Outer diameter

Catalogue card

Download

Family datasheet

Download

Family datasheet extended

Download

Installation manual

462.17 KB

Download

EC Declaration of conformity

Download

Photometric file

808 B

Download

Pobierz wszystkie pliki

Installation elements

Bari DLN LED Suspension set 3x
