Architectural
Seven LED
LED architectural luminaire. Perfect solution for discreet lighting of building surroundings, paths and gardens. Possibility of painting in any RAL colour.
Architectural
Seven LED
LED architectural luminaire. Perfect solution for discreet lighting of building surroundings, paths and gardens. Possibility of painting in any RAL colour.
Go to the variant list (16)
LED
ON/OFF
DI
IP65
II
yes
yes
Basic information:
Materials:
Housing made of aluminum painted with paint resistant to external conditions (standard color: graphite, other colors on request), diffuser made of tempered glass.
Accessories:
base for concrete, base to the ground
Installation:
For the ground
Power:
220 ... 240 V
Categorization:
Type of luminaire:
Architectural
Application:
Apartment building environment, Building environment, Car park, Park, Sport field
Mounting type:
Bollard
Technical data:
Luminaire power:
5.5 - 9.5 W
Luminaire luminous flux:
460 - 880 lm
Length:
100 mm
See other technical data
Technical data Product variants Download
Description of the product's family

LED COB protection - transparent tempered glass

Side view

Zdjęcie po
Zdjęcie przed
Before
After
Technical data
Mechanical data
Housing material Aluminum
Optical data
Louver/ diffuser LNS
Electrical data
Light source LED
Luminaire power 5.5 - 9.5 W
Type of equipment AC
Voltage rating 220 ... 240 V
Through wiring No
Type of driver ON/OFF
Emergency module option
Motion sensor option
Information data
Net weight 1.9 - 2.4 kg
Colour Anthracite
Power and luminous flux tolerance +/-10%
Light data
Luminaire luminous flux 460 - 880 lm
Luminaire's luminous efficacy 84 - 93 lm/W
Color rendering index 80
Light distribution DI
Colour temperature 3000K, 4000K
CRI & colour temperature 830, 840
Certificates
Degree of protection (IP) IP65
Class of protection II
Light source protection yes
CE yes
HACCP+ yes
EAC yes
Product variants
✕
Search
Filtry
How does the product indexing system work?
AA
002
.
22
11
.
830
.
D
0
0
0
Family
AA ALTO LED
AB ALTO WALL
Type
001 e.g.: 545 mm
002 e.g.: 1085 mm
Colour
11 WHITE RAL 9016
12 WHITE RAL 9010
22 GREY RAL 9006
33 BLACK RAL 9005
44 ANTHRACITE RALBG 452
45 ANTHRACITE RAL 7016
99 OTHER - PERSONALIZATION
Optical system
00 EMPTY
11 OPAL /MILK DIFFUSER/
22 MPRM /MICROPRISMATIC DIFFUSER/
23 DMPRM /DIAMONT MICROPRISMATIC DIFFUSER/
24 MPOP /MICROPRISMATIC DIFFUSER WITH FLEX LAYER/
33 PAR /PARABOLIC LOUVER/
34 PAR SH /PARABOLIC LOUVER UNDER TEMPERED GLASS/
44 mPARM /PARABOLIC MINI LOUVER METALLIZED/
45 PARW /PARABOLIC LOUVER WHITE/
46 mPARB /PARABOLIC MINI LOUVER BLACK/
66 RF /REFLECTOR/
67 RM /MATTE REFLECTOR/
68 RW /REFLECTOR WHITE/
77 LNS /LENS/
88 SH MAT /MATTE TEMPERED GLASS/
89 SH /TEMPERED GLASS/
CRI / Colour temp.
827
830 CRI ≥ 80; CCT 3000K
835 CRI ≥ 80; CCT 3500K
840 CRI ≥ 80; CCT 4000K
850 CRI ≥ 80; CCT 5000K
857 CRI ≥ 80; CCT 5700K
865 CRI ≥ 80; CCT 6500K
8TW CRI ≥ 80; Tunable white
927 CRI ≥ 90; CCT 2700K
930 CRI ≥ 90; CCT 3000K
935 CRI ≥ 90; CCT 3500K
940 CRI ≥ 90; CCT 4000K
950 CRI ≥ 90; CCT 5000K
957 CRI ≥ 90; CCT 5700K
965 CRI ≥ 90; CCT 6500K
9TW CRI ≥ 90; Tunable white
RGB RGB
Driver
A ON/OFF /WITHOUT REGULATION/
D DALI /DIGITAL ADDRESSABLE LIGHTING INTERFACE/
H HO /DRIVER WITH PREDEFINED SETTING/
E HE /DRIVER WITH PREDEFINED SETTING/
F HO DALI /DRIVER WITH PREDEFINED SETTING/
G HE DALI /DRIVER WITH PREDEFINED SETTING/
K DSI
I CF /CORRIDOR FUNCTION - STEP DIMMING/
C CAS /CASAMBI - SMART CONTROL VIA APPLICATIONS/
X DMX
S sDIMM
V 1-10V /ADJUSTABLE/
Emergency module
0 WITHOUT EMERGENCY MODULE
1 EM1H ST /SELFTEST/
2 EM3H ST /SELFTEST/
3 EM1H BASIC
4 EM3H BASIC
5 EM1H PRO /DALI/
6 EM3H PRO /DALI/
Through wiring
0 WITHOUT THROUGH WIRING
1 TH3 /3-PHASE THROUGH WIRING/
2 TH5 /5-PHASE THROUGH WIRING/
3 TH7 /7-PHASE THROUGH WIRING/
4 WI /WIELAND/
5 WI TH /THROUGH WIRING/
Motion sensor
0 WITHOUT MOTION SENSOR
1 MW PRO /PASSIVE INFRARED - STEP DIMM/
2 PIR /INFRARED/
Technical data
Dimensions
Filtrowanie po parametrach
Parametry
Luminaire power
Show products
Luminous flux
Show products
CRI / Colour temp.
Select all
Reset
Show products
Optics
Select all
Reset
Show products
Type of family
Select all
Reset
Show products
Index
Luminaire power
Luminaire luminous flux
Luminaire's luminous efficacy
Optics
Louver/ diffuser
[Optical system]
CRI & colour temperature
Colour
Type of driver
Type of family
HU001.4477.830.A000
Copy the code
Open in new window
5.5 W 470 lm 85 lm/W ST LNS 830
Anthracite
 ON/OFF 5W 600mm ST
HU001.4477.840.A000
Copy the code
Open in new window
5.5 W 500 lm 91 lm/W ST LNS 840
Anthracite
 ON/OFF 5W 600mm ST
HU002.4477.830.A000
Copy the code
Open in new window
9.5 W 830 lm 87 lm/W ST LNS 830
Anthracite
 ON/OFF 10W 600mm ST
HU002.4477.840.A000
Copy the code
Open in new window
9.5 W 880 lm 93 lm/W ST LNS 840
Anthracite
 ON/OFF 10W 600mm ST
HU003.4477.830.A000
Copy the code
Open in new window
5.5 W 470 lm 85 lm/W ST LNS 830
Anthracite
 ON/OFF 5W 900mm ST
HU003.4477.840.A000
Copy the code
Open in new window
5.5 W 500 lm 91 lm/W ST LNS 840
Anthracite
 ON/OFF 5W 900mm ST
HU004.4477.830.A000
Copy the code
Open in new window
9.5 W 830 lm 87 lm/W ST LNS 830
Anthracite
 ON/OFF 10W 900mm ST
HU004.4477.840.A000
Copy the code
Open in new window
9.5 W 880 lm 93 lm/W ST LNS 840
Anthracite
 ON/OFF 10W 900mm ST
HU005.4477.830.A000
Copy the code
Open in new window
5.5 W 460 lm 84 lm/W AS LNS 830
Anthracite
 ON/OFF 5W 600mm AS
HU005.4477.840.A000
Copy the code
Open in new window
5.5 W 490 lm 89 lm/W AS LNS 840
Anthracite
 ON/OFF 5W 600mm AS
HU006.4477.830.A000
Copy the code
Open in new window
9.5 W 810 lm 85 lm/W AS LNS 830
Anthracite
 ON/OFF 10W 600mm AS
HU006.4477.840.A000
Copy the code
Open in new window
9.5 W 860 lm 91 lm/W AS LNS 840
Anthracite
 ON/OFF 10W 600mm AS
HU007.4477.830.A000
Copy the code
Open in new window
5.5 W 460 lm 84 lm/W AS LNS 830
Anthracite
 ON/OFF 5W 900mm AS
HU007.4477.840.A000
Copy the code
Open in new window
5.5 W 490 lm 89 lm/W AS LNS 840
Anthracite
 ON/OFF 5W 900mm AS
HU008.4477.830.A000
Copy the code
Open in new window
9.5 W 810 lm 85 lm/W AS LNS 830
Anthracite
 ON/OFF 10W 900mm AS
