Series of luminaires recommended for industrial areas and for clean rooms where increased IP protection degree is required. Luminaires are available both in CRI>80 and increased CRI>90. Luminaires dedicated for installation in recessed and 600x600 ceiling with visible grid. Luminaire is suitable for use in cleanrooms fulfilling the specification of air cleanliness ISO Class 3 - 9 according to ISO 14644-1:2015. Qualification certificate "ISO 14644-14 Cleanroom suitability test: particle emission test".
The luminaire is ENEC certified.
Series of luminaires recommended for industrial areas and for clean rooms where increased IP protection degree is required. Luminaires are available both in CRI>80 and increased CRI>90. Luminaires dedicated for installation in recessed and 600x600 ceiling with visible grid. Luminaire is suitable for use in cleanrooms fulfilling the specification of air cleanliness ISO Class 3 - 9 according to ISO 14644-1:2015. Qualification certificate "ISO 14644-14 Cleanroom suitability test: particle emission test".
The luminaire is ENEC certified.
| Type of installation | For 600x600 ceiling |
| Housing material | Steel sheet |
| Louver/ diffuser | OPAL |
| Diffuser colour | White |
| Diffuser material | Opal/mat plastic |
| UGR | 20 |
| Light source | LED |
| Luminaire power | 43 W |
| Number of light sources | 1 |
| Type of equipment | AC |
| Voltage rating | 220 ... 240 V |
| Through wiring | No |
| Light source included | yes |
| Power factor | 0.96 |
| Type of driver | ON/OFF |
| Emergency module | No |
| Motion sensor | No |
| Net weight | 7.9 kg |
| Colour | White |
| RAL - any color from the palette | yes |
| Power and luminous flux tolerance | +/-10% |
| Info | 300x1200 |
| Luminaire luminous flux | 4910 lm |
| Luminaire's luminous efficacy | 114 lm/W |
| Light colour | White |
| Color rendering index | 80 |
| Light distribution | DI |
| Class of luminaire | I |
| MacAdam | SDCM 3 |
| Lifetime L80B10 @25°C | 100000 h |
| Lifetime L90B10 @25°C | 64000 h |
| Lamp Lumen Maintenance Factor (after 60 000h) | 85 % |
| Colour temperature | 4000K |
| CRI & colour temperature | 840 |
| Degree of protection (IP) /top/ | IP65 |
| Degree of protection (IP) /bottom/ | IP65 |
| Impact resistance | IK08 |
| Class of protection | I |
| Power Flicker | =< 3% |
| Light source protection | yes |
| PZH | yes |
| CE | yes |
| ENEC | yes |
| HACCP+ | yes |
| ISO 14644-14 (air cleanliness ISO Class 3 - 9) | yes |
| L | W | H |
|---|---|---|
| 1195 mm | 295 mm | 85 mm |
