Type of installation | Ceiling mounted |
Housing material | Aluminum |
Louver/ diffuser | OPAL |
Diffuser colour | White |
Diffuser material | Opal/mat plastic |
Reflector | high gloss |
UGR | 22 |
Light source | LED |
Luminaire power | 7 W |
Number of light sources | 1 |
Type of equipment | AC |
Voltage rating | 220 ... 240 V |
Through wiring | No |
Light source included | yes |
Type of driver | ON/OFF |
Emergency module | No |
Motion sensor | No |
Net weight | 1 kg |
Colour | Grey |
Operating temperature range | -15 ... 40 |
Power and luminous flux tolerance | +/-10% |
Info | OPAL |
Luminaire luminous flux | 765 lm |
Luminaire's luminous efficacy | 109 lm/W |
Light colour | White |
Color rendering index | 80 |
Light distribution | Wide beam |
Light distribution | DI |
Class of luminaire | I |
Light output degradation | B10 |
Lumen maintenance | L80 |
Lifetime | 54000 h |
MacAdam | SDCM 3 |
Lamp Lumen Maintenance Factor (after 60 000h) | 85 % |
Colour temperature | 3000K |
CRI & colour temperature | 830 |
Degree of protection (IP) | IP44 |
Impact resistance | IK04 |
Class of protection | I |
Light source protection | yes |
PZH | yes |
CE | yes |
HACCP+ | yes |
EAC | yes |
L | W | H |
---|---|---|
300 mm | 65 mm | 65 mm |
